Muti-Tank Industrial ITO Conductive Glass Automatic Ultrasonic Cleaning Machine for

1. Definition

The Industrial ITO (Indium Tin Oxide) Conductive Glass Automatic Ultrasonic Cleaning Machine is specialized equipment designed for the meticulous cleaning of ITO conductive glass. ITO conductive glass, widely used in touchscreens, liquid crystal displays (LCDs), and other optoelectronic devices, requires high - precision cleaning to remove contaminants such as dust, oil stains, fingerprints, and residual chemicals. This machine integrates ultrasonic technology, automated control systems, and multiple cleaning processes to ensure thorough and consistent cleaning of ITO conductive glass, meeting the stringent requirements of the modern optoelectronic industry.

2. Working Principle

Ultrasonic Cavitation: The core of the cleaning process is ultrasonic cavitation. When ultrasonic waves propagate through the cleaning liquid, they generate numerous tiny vacuum bubbles (cavities). These bubbles expand under the action of rarefaction waves and then collapse violently under the compression waves. The high - speed implosion of these bubbles generates intense shockwaves and micro - jets, which can reach extremely high local temperatures and pressures. These forces effectively dislodge and remove contaminants adhered to the surface of ITO conductive glass, even in microscopic crevices and pores.
Automated Cleaning Processes: The machine is equipped with an automated system that controls the entire cleaning process. This includes functions such as automatic feeding and discharging of glass substrates, sequential cleaning in multiple cleaning tanks filled with different cleaning agents (such as alkaline cleaning solution, acid cleaning solution, deionized water for rinsing), and precise control of cleaning time, temperature, and ultrasonic power in each stage. This automated and multi - stage cleaning approach ensures comprehensive and efficient cleaning of ITO conductive glass.

3. Product Features and Advantages
Features
High - precision Cleaning: Capable of achieving thorough cleaning of ITO conductive glass, removing the tiniest contaminants to ensure the high - quality surface required for optoelectronic applications.
Automated Operation: With fully automated feeding, cleaning, rinsing, and drying processes, it significantly reduces manual labor, improves production efficiency, and minimizes human - error - related quality issues.
Multi - stage Cleaning System: Consists of multiple cleaning tanks with different cleaning agents and processes, including degreasing, descaling, and final rinsing, to address various types of contaminants.
Adjustable Parameters: Allows users to adjust ultrasonic power, cleaning time, temperature, and other parameters according to different glass specifications and cleaning requirements, providing flexibility for diverse production needs.
Customizable:This product support non-standard custom, can provide design drawings and cleaning program.
Advantages

Improved Product Quality: By ensuring clean ITO conductive glass surfaces, it enhances the performance and reliability of optoelectronic products, reducing the occurrence of defects such as display anomalies and touch - screen malfunctions.
Increased Productivity: The automated and continuous operation mode enables high - volume production, meeting the demands of large - scale manufacturing in the optoelectronic industry.
Cost - effective: Reduces labor costs through automation and minimizes the consumption of cleaning agents due to precise process control. Additionally, the extended lifespan of the equipment and reduced reject rates further contribute to cost savings.
Environmental - friendly: Many models adopt environmentally friendly cleaning agents and efficient water - recycling systems, reducing the environmental impact while maintaining excellent cleaning performance.

4.The Commom technical parameters

5.Cleaning process:

Here are the common cleaning processes of the industrial ITO conductive glass automatic ultrasonic cleaning machine:

Loading: The ITO conductive glass is placed on the automatic feeding device. The device can accurately position the glass to ensure it enters the cleaning chamber smoothly.

Pre - cleaning: The glass is first immersed in a pre - cleaning tank filled with a mild alkaline cleaning solution. This solution is used to remove large - particle dust and grease. The ultrasonic system works simultaneously, with a relatively low - frequency ultrasonic wave (such as 20 - 30kHz) to preliminarily loosen the contaminants on the glass surface.

Main Cleaning:The glass is then transferred to the main cleaning tank, which contains a stronger alkaline or acidic cleaning solution depending on the type of contaminants. High - frequency ultrasonic waves (usually 40 - 80kHz) are applied. The intense cavitation effect generated by the ultrasonic waves thoroughly removes various stubborn contaminants, including metal oxides and organic residues, from the surface and pores of the ITO conductive glass.

Rinsing: After the main cleaning, the glass is rinsed in multiple stages with deionized water. The first rinsing stage uses low - pressure deionized water to remove most of the cleaning solution on the glass surface. Then, in the subsequent rinsing stages, high - pressure deionized water jets are used to further clean the glass, ensuring that no cleaning agent residue remains.

Drying: Finally, the glass is dried using a hot air drying or nitrogen drying system. Hot air drying blows heated air (usually at 50 - 80°C) onto the glass surface to evaporate the remaining water. Nitrogen drying uses high - purity nitrogen gas to quickly dry the glass, achieving a clean and dry surface suitable for subsequent processing.

Unloading:The dried ITO conductive glass is automatically unloaded from the cleaning machine and transferred to the next production process.

6. Application Areas

• Liquid Crystal Display (LCD) Manufacturing: Used to clean ITO conductive glass substrates before processes such as thin - film transistor (TFT) deposition, liquid crystal cell assembly, and polarizer attachment, ensuring high - quality display performance.
• Touchscreen Production: Essential for cleaning ITO conductive glass used in resistive and capacitive touchscreens, which helps improve touch sensitivity and accuracy, and reduces the occurrence of dead spots.
• Solar Cell Industry: Applies to the cleaning of ITO - coated glass used in solar cells, enhancing the efficiency of light absorption and electrical conductivity, and ultimately improving the overall performance of solar panels.
• Optical Devices and Semiconductor Manufacturing: Can be used to clean other optical glass components and semiconductor - related glass substrates, where high - precision cleaning is crucial for product quality and functionality.

1.Quality Control:

We are using hight quality material like Simens, Schneider electrical parts. Our machine is designed by experienced engineer who have designed machines for Foxconn, Cummins and BOSCH. The workers also have years experience building automatical cleaning line. Our QC system is covering from raw material to finishing machine.

2.Professional Experience:

We have worked with many famous brand company and goverment project like Foxconn, Cummins and railway department. We also have 20 years international experience with installating and testing machine in other country. We will provide full service for our customer after purchasing.

3.Payment Term:

We can accept flexible payment term due to different situation like 10~20% payment after installation and test service.

We also need some support from you in some case.

4.After Sales Service:

We will provide installation and test service for automatical cleaning line at your facility until cleaning is working properly.

And we offer 5 years with 24/7 work during warranty period.

5.Professional customization

The company can professionally customize various types of cleaning machines to provide customers with cost-effective cleaning solutions to meet your one-stop procurement services.

Cleaning Effect:
